Description
- Aluminum Molded Construction
- Easy temperature & Stir controls
- Installed with Safety PT sensor for fail safe operation.
- Hot top indicator for temperatures above 50°C.
- Large top plate to assist beakers up to 2000 ml.
- High magnetic strength.
- Electronic variable speed control with Knob for display.
- Knob for regulating variable temperature.
- Heat reach Indicator, To ensure you correct temperature of plate surface.
- Stirring & temperature indicator
- Error indicators for heat & Stir function inbuilt trouble shoot
- Hot top warning indicator for temperature >50°C
Technical Specification:
| Heating Mantle Material | Stainless Steel 304 Grade/ Ceramic Coated |
| Dimension of heating plate | 150 Ø |
| Speed range | 50-1600 RPM |
| Maximum stirring bar Length | Can use up to 80 mm bar (at lower speed) |
| Temperature Range | Ambient to 350°C ~app |
| Dimensions of hot plate body | 273x160x102mm |
| Weight of body | 2.8 kgs |
| Permissible ambient Temperature | 5- 40 °C |
| Permissible relative moisture | 80% |
| IP Class | 22 |
| Also Known as | 900.DG.01 |
Included Accessory:
| Cat. No. | Accessories |
|---|---|
| 850.800.02 | Magnetic Stirring bar 35 mm x 9 mm |
| Temp Control | RPM | Plate Size | Vessel Capacity | Plate Material |
|---|---|---|---|---|
| Variable up to 350° C | 1600 RPM | 150mmØ | up to 2L Beakers | SS 304 Grade |
